Features - UP-Most High Resolution : Color - 550TV Lines / B/W - 600 TV Lines - Built - In Next Generation 3D DNR with 3D Filter - Max. Sens-Up (×258), 0.00001 Lux of Min. lllumination - Convenient OSD control function - ×32 Digital Zoom - Free Area Selectable function of BLC and MD - Privacy Color Masking for 8 Area selection - Camera OSD control by RS-485(Option) - ICR-IR Infrared Cut Filter Removable(Option) - Max 70% of Disk Saving Effect with Super DNR - Negative Image Function - Digital Wide Dynamic Range Function(D-WDR)

Specification

Image Pick-up Device 1/3" Sony Super HAD CCD Effective Pixels 768 (H) x 494 (V) Scanning Frequency 15.734 KHz (H) / 59.94 Hz (V) Scanning System 2:1 Interlace Synchronization Internal OSD Available Backlight Off / HSBLC / BLC Selectable Resolution 550 TV Lines (Color), 600 TV Lines (B&W) S/N 52 dB (AGC Off, Weight On) Min. Illumination 0.00001 Lux (Sens-Up * 258) White Balance ATW / AWB / Manual / AWC --> Set Electronic Shutter Speed Auto (1/50 sec, 1/60 sec ~ 1/120,000 sec) Sense-Up Off / Auto (Selectable Limi *2 ~ *258) Gain Control High, Middle, Low, Off Selectable) 3 DNR Off / On (1~50 Levels Adjustable) D-WDR Indoor / Outdoor / Off Motion Detection On/Off (4 Zone, Alarm Output) Privacy On/Off (8 Zones) Mirror Off / Mirror / V-Rev / Rotate Freeze On / Off Sharpness 0~31' (Level Adjustable) D&N Selection Color/BW/Auto Digital Zoom On (*32) / Off Blemish Compensation 256 Point (Even 128 Point, ODD 128 Point) Power DC 12V (Dual Power 24V AC/DC12V)-Optional Power Consumption 120mA Lens DC Auto Iris Varifocal Lens (2.8mm-12mm) Operating Temperature -10c ~ +50c, RH 95% Max Storage Temperature -10c ~ +60c, RH 95% Max Dimension 139 mm (W) * 97 mm (H) * 139 mm (D) Weight 700g
